Home > ASTM A182 F60 Fasteners
Majid Fasteners, a leading manufacturer and supplier located in Dubai, UAE, specializes in high-quality ASTM A182 F60 Fasteners that are built to perform exceptionally well in tough industrial settings. These duplex stainless steel fasteners boast impressive strength, corrosion resistance, and durability, making them perfect for environments rich in chlorides and under high pressure. Majid Fasteners produces F60 bolts, nuts, washers, studs, and tailored fastening solutions that adhere to international standards and can handle aggressive media. Their F60 fasteners are highly regarded in marine, offshore, petrochemical, and chemical sectors, where reliability and structural integrity are crucial for critical operations.
ASTM A182 F60 Fasteners are made from duplex stainless steel, featuring around 23% chromium, 5–6% nickel, 3% molybdenum, and controlled nitrogen to boost strength and corrosion resistance. This alloy is known for its exceptional resistance to pitting, crevice corrosion, and chloride stress corrosion cracking. F60 fasteners deliver high tensile and yield strength, along with impressive fatigue resistance and good impact toughness. Their duplex microstructure strikes a perfect balance between hardness and ductility, ensuring reliable performance in high-stress, high-temperature, and chemically aggressive environments.
| dentification Symbol | UNS Number | Grade | Elements | Composition % |
|---|---|---|---|---|
| F60 | S32205 | 22 chromium, 5.5 nickel, 3 molybdenum, modified with nitrogen 2205 | Carbon | 0.030 max |
| Manganese | 2.00 max | |||
| Phosphorus | 0.030 max | |||
| Sulfur | 0.020 max | |||
| Silicon | 1.00 max | |||
| Nickel | 4.5 – 6.5 | |||
| Chromium | 22.00 – 23.00 | |||
| Molybdenum | 3.00 – 3.5 | |||
| Nitrogen | 0.14 – 0.20 |
| Standard | ASTM, BS, ASME, ISO, UNI, ANSI, GB, IS, DIN, JIS Fasteners |
|---|---|
| Threads: | BSF, BSW, UNF, UNC, METRIC or as per need |
| Astm A182 Grade F60 Bolts Standard | ANSI
|
| ASTM A182 GR. F60 Fasteners / Bolts Size | M6, M30, M12, M10, M16, (M45), M4, M8, M2, M24, (M3.5), M33, M20, M42, (M14), M5, M48, (M18), (M27), (M22), M36, M3, M160 and as per need |
| Length | 3 milimeter – 200 milimeter |
| Head drive: | Slotted, Six-Lobe, Phillips/Slot, Phillips, etc |
| Bolts Test Certificate | EN 10204 / 3.1 |
| Duplex Grade F60 Fasteners raw materials of Source | Usha Martin, JSPL, Mukund Steel, Tata Steel, Dhamm Steel, RINL etc. |
| Form | Square, Hex, Threading as per Gauge, Round Etc. |
| Astm A182 Grade F60 Bolts Process of Production |
|
| Duplex Steel Gr F60 Fasteners Surface Coating |
|
| Property | Value |
|---|---|
| Tensile Strength, min, ksi [MPa] | 95 [655] |
| Yield Strength, min, ksi [MPa] | 65 [450] |
| Elongation in 2 in. [50mm] or 4D, min, % | 25 |
| Reduction or Area, min, % | 45 |
| Brinell Hardness Number, HBW | — |
ASTM A182 F60 Fasteners find extensive use in applications that require both high strength and strong corrosion resistance. They are frequently utilized in offshore platforms, marine structures, and subsea equipment that face harsh seawater conditions. The oil and gas industry depends on F60 fasteners for pipelines, manifolds, valves, and high-pressure processing units. In chemical and petrochemical plants, they are essential for heat exchangers, pumps, reactors, and storage tanks due to their ability to withstand aggressive fluids. Additionally, these fasteners are ideal for various other applications where durability and reliability are paramount.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
