Majid fasteners is a reliable producer and distributor of superior industrial fasteners in Dubai, UAE, and its products enjoy international standards of quality. We are also specialists in ASTM A193 B8M stud bolts which are corrosion-resistant, high-strength fasteners that can be used in chemical, petrochemical, oil and gas, and marine applications. Proceeding with the precision, durability, and customer satisfaction philosophy, Majid Fasteners guarantees a consistent fastening system that works remarkably well even in the most severe conditions to uphold the safety, efficiency, and longevity of the most important industrial machinery.
Austenitic stainless steel, which is mostly made of iron with chromium (18–20%), nickel (8–11%), molybdenum (2–3%), carbon (≤0.08%), manganese (≤2%), phosphorus (≤0.045%), and sulfur (≤0.03%), is used to make ASTM A193 B8M stud bolts. This composition offers high strength and excellent corrosion resistance, particularly in acidic and marine environments. The mechanical characteristics include a minimum elongation of 40%, a yield strength of 205 MPa, and a tensile strength of 515 MPa. Because of these qualities, B8M stud bolts can be used in petrochemical, chemical, and marine industries for corrosive, high-temperature, high-pressure applications.
|
Material
|
Specification
|
Standards |
Size
|
Length
|
|
ASTM A193 B8M StudBolt
|
IS BS ASTM
|
DIN, ISO, JIS, GB, IS, BS, ASTM |
M 02 to M 160
|
3 mm to 200
|
| Element | B7 | B8 | B8M |
| Carbon | 0.37 – 0.49% | 0.08% max | 0.08% max |
| Manganese | 0.65 – 1.10% | 2.00% max | 2.00% max |
| Phosphorus, max | 0.035% | 0.045% | 0.045% |
| Sulfur, max | 0.040% | 0.030% | 0.030% |
| Silicon | 0.15 – 0.35% | 1.00% max | 1.00% max |
| Chromium | 0.75 – 1.20% | 18.0 – 20.0% | 16.0 – 18.0% |
| Nickel | 8.0 – 11.0% | 10.0 – 14.0% | |
| Molybdenum | 0.15 – 0.25% | 2.00 – 3.00% |
| Grade | Size | Tensile ksi, min | Yield, ksi, min | Elong, %, min | RA % min |
| B7 | Up to 2-1/2 | 125 | 105 | 16 | 50 |
| 2-5/8 – 4 | 115 | 95 | 16 | 50 | |
| 4-1/8 – 7 | 100 | 75 | 18 | 50 | |
| B8 Class 1 | All | 75 | 30 | 30 | 50 |
| B8M Class 1 | All | 75 | 30 | 30 | 50 |
| B8 Class 2 | Up to 3/4 | 125 | 100 | 12 | 35 |
| 7/8 – 1 | 115 | 80 | 15 | 35 | |
| 1-1/8 – 1-1/4 | 105 | 65 | 20 | 35 | |
| 1-3/8 – 1-1/2 | 100 | 50 | 28 | 45 |
ASTM A193 B8M stud bolts are widely applied in those industries, which demand corrosion-free and high-strength fasteners. They can be used in chemical processing, petrochemical, oil and gas, marine and food processing processes where the conditions are prone to corrosive environments, high temperatures, and pressures. These bolts are extensively used to connect flanges, valves, pumps, pressure, and pipelines in order to have strong and reliable connections. Their strong resistance to oxidation, acids and unreliable mechanical performance, in conjunction with other attributes, is crucial to critical industrial equipment and brings about safety, durability and efficiency to equipment within hard working environments.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
