Majid Fasteners is a leading manufacturer and distributor of fasteners in Dubai, UAE, which is specialized in the manufacture of high quality fasteners such as Duplex Steel S32205 bolts. These bolts have been known to perform exceptionally well in strength, durability and corrosion resistance and are suitable in applications where high demands are required such as in industries, marine and construction. At Majid Fasteners, all the products are of high quality and we maintain stringent standards of the international level through modern manufacturing process and strict inspection of quality. We have a strong focus on reliability, competitive pricing, and prompt delivery which makes us the best option to clients in both local and international markets in the UAE.
The chemical composition of Duplex Steel S32205 Bolts is approximately 22% Chromium, 5 to 6% Nickel, 3% Molybdenum, 0.14% – 0.20% Nitrogen, which provides good corrosion resistance and strength to the material. Their dual-phase structure (Austenitic-Ferritic) allows them to perform extremely well mechanically; the tensile strength of Duplex Steel S32205 Bolts is generally between 680 and 850 MPa, and their yield strength generally ranges from 450 to 550 MPa. The high level of corrosion resistance exhibited by these bolts is due to their ability to resist both pitting corrosion and stress-corrosion cracking and is therefore highly desirable in environments that are considered aggressive. With their combined properties of toughness, durability, and high load-bearing capacity, Duplex Steel S32205 Bolts are an excellent choice for use in Chemical Processing, Marine, Offshore, and Industrial applications.
| Specifications | : | ASTM A 479 ASME SA 479 |
| Standard | : | DIN, ASTM, BS and all International Standards |
| Length | : | 3 mm to 200 mm |
| Size | : | M3 – M56 | 3/6″ to 2″ | Custom Sizes |
| Type | : | Hex Head Bolts, Square Bolts, U bolts, Eye bolts, T bolt, Hex Bolt, Lag Bolts, Counter sunk Bolts, Hex Head nuts, Square nuts, Lock nuts, Eye nuts, wing nuts, T nuts, Panel Nuts, Coupling Nuts, Dome nuts, Acorn Nuts. |
| Cr | N | Ni | C | Mn | Si | P | S | Mo | |
|---|---|---|---|---|---|---|---|---|---|
| UNS S32205 Bolts | min: 22.0 max: 23.0 | min: 0.14 max: 0.20 | min: 4.5 max: 6.5 | 0.03 max | 2.0 max | 1.0 max | 0.03 max | 0.02 max | min: 3.0 max: 3.5 |
|
Grade |
Tensile Strength
(MPa) min |
Elongation
(% in 50mm) |
Yield Strength
0.2% Proof (MPa) min |
Hardness
Rockwell C (HR C) |
|---|---|---|---|---|
|
UNS-S 32205 Bolts |
621 |
25 |
448 |
21 max |
S32205 Duplex Material Bolts has a wide range of applications throughout all sectors that require exceptional strength with corrosion resistance capabilities. The durability of duplex steel fasteners has made them an ideal choice in industries such as chemical processing facilities, oil and gas platforms and desalination plants, where there may be frequent exposure to harsh, highly corrosive conditions. For these reasons they are used extensively in marine and offshore industries, including but not limited to shipbuilding, coastal infrastructure and offshore drilling operations, because of their immunity to seawater corrosion. They are also highly recommended for the construction, petrochemical and power generation industries where extreme loading and difficult environmental conditions exist.S32205 Duplex Fasteners provide an economical means of achieving long-term reliable fastening solutions required by many demanding industrial, marine and structural applications.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
