Majid Fasteners manufacture and supply top-quality industrial fasteners based in Dubai, UAE, and are recognized for their quality and durability. Focusing on Duplex Steel stud bolts, Majid Fasteners offers a complete line of fasteners with high strength, outstanding corrosion resistance, and long-term performance in Offshore Marine Chemical and Oil & Gas industries. Majid Fasteners is a valued partner to companies looking for quality, on-time delivery, and customer service regarding the production of Secure and durable fasteners for many different high-performance industrial applications.
Typical Duplex Steel Stud Bolts have a balanced austenitic/ferritic micro-structure with an average composition of 21-23% Chromium, 4.5-6.5% Nickel, 2.5-3.5% Molybdenum, and 0.14-0.20% Nitrogen. Other trace elements include Manganese, Silicon, and Copper. The chemical composition of Duplex Steel Bolts gives the material superior resistance to pitting, crevice corrosion, and stress corrosion cracking in a chloride-rich environment. The mechanical properties of Duplex Steel Bolts allow for a tensile strength range of 620-880 MPa and a yield strength range of 450-550 MPa; they also provide an excellent level of toughness, have a high level of fatigue resistance, and are able to maintain their mechanical properties in elevated temperature/pressure applications within the industrial, marine, and chemical industries.
| Specifications | ASTM A 479 ASME SA 479 |
| Dimension | DIN, ASTM, BS and all International Standards |
| Length | 3mm to 200mm |
| Size | M3 – M56 | 3/6″ to 2″ | Custom Sizes |
| Types | Threaded Rod, Class A double ended stud, Tie Rod, Double Ended Stud, Stud Bolts, Bronze Hex Studs, Threaded Studs etc |
| Duplex Steel Stud Bolts | C | N | P | Si | Mn | Mo | Fe | Cr | S | Ni |
| 1.0 | 0.03 | 0.02 | 2.0 | 3.0 – 3.5 | 22.0 – 23.0 | 0.03 | 4.5 – 6.5 | 0.14 – 0.2 | Bal |
| Duplex Steel Stud Bolts | Density | Melting Point | Yield Strength (0.2%Offset) | Tensile Strength | Elongation |
| 7.8 g/cm3 | 1350 °C (2460 °F) | Psi – 80000 , MPa – 550 | Psi – 116000 , MPa – 800 | 15 % |
Duplex Steel stud bolts are a widely used industrial fastener due to their higher strength, corrosion resistance, and durability than conventional steel fasteners under harsh working conditions. Duplex Steel stud bolts are designed for use on offshore drilling and production platforms, subsea (underwater) equipment, and other marine structures subject to seawater or near-chloride environments. In the oil and gas industry, they are frequently used in applications such as pipelines, high-pressure equipment (pressure vessels and heat exchangers), and in applications involving very high stress. They are also specifically designed for applications within chemical processing plants that handle corrosive chemicals and elevated temperature operations. duplex steel stud bolts are also found in desalination plants, power generation equipment, heavy industrial machinery, and other situations that require optimal performance under high levels of corrosion and demanding service conditions over an extended period of time.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
