Majid fasteners is a prominent producer and distributor of high-performance industrial fasteners in Dubai, UAE, as well as a dedicated firm to provide quality, accuracy and reliability of its products unparalleled. Our high quality products include Hastelloy C276 Bolts that are designed to be highly corrosion resistant and durable and have a successful performance in environments of the most extreme corrosion and extreme temperature. These bolts are used in long-term applications in chemical processing, offshore, and petrochemical applications, which have long integrity and safety. We offer fastening solutions with modern manufacturing experience, quality control, and that is higher than the expectations of the industry.
Hastelloy C276 Bolts are made up of nickel (Ni), chromium (Cr), molybdenum (Mo), with small quantities of tungsten (W) and very low levels of carbon (C). This alloy provides excellent resistance to pitting, crevice corrosion, and SCC in both oxidising and reducing environments. In addition to its excellent corrosion-resistant properties, Hastelloy C276 Bolts also have superior mechanical properties such as: high tensile strength, high yield strength, good ductility, and superior performance at elevated temperatures. They also support high levels of structural integrity under pressure and thermal stress, giving them long-term reliability in the chemical processing, offshore, and very harsh industrial environments.
| Specifications | ASTM B574 / ASME SB574 |
|---|---|
| Fasteners size | Bolt / Screw Size : M3 – M56 | 3/6″ to 2″ | Custom Sizes Nuts Size : M3 – M56 | 3/6″ to 2″ | Custom Sizes Washers Size : M3 – M56 | 3/6″ to 2″ | Custom Sizes Machine Screws Size : M1.6 – M12 Self Tapping Screw Size : No.2 – No. 14 |
| Fasteners Length | 3 mm to 200 mm |
| Fastener Threads | UNF, BSW, BSF, METRIC, UNC or as required |
| Standard of High Nickel Alloy Fasteners | DIN : DIN 934, DIN 931, DIN 970, DIN 933 UTS : UNEF, NPT, UNC, UNS, UNF, NPTF ISO : JIS standards, ISO 4033, ISO 4032, ANSI – American National Standards Institute ASME B18.5 ANSI B 28.2.4 1M as per defined in ASME B16.5 standard Stud Bolt length ANSI B 18.2.4 2M as per defined in ASME B18.2.2 Hex nuts |
| Dimensions | DIN 931, 933, 934, 7991, 976, 125, ASME B18.2.1, B18.3 |
| Surface Coating | Ptfe Coated High Nickel Alloy Fasteners Phosphate Coating Teflon Coating Zinc Coating Hot Dipped Galvanizing Coating Cadmium Coating Xylon Coating |
| Fasteners Finishing | High Nickel Alloy : Self-Colour, Passivated, Bright Zinc Plated (BZP), Hot Dip Galvanised (HDG), High Nickel Alloy, Sherardized, some special one like DACROMET Geometry and Mechanically Applied coating ,Dacroment, nickel plated, anodizing, plated zinc-nickel Zinc (blue, black, yellow, white), black oxide. |
| Grade | C | Mn | Si | Co | S | Ni | Cr | Fe | Mo | W | V | P |
| Hastelloy C276 Bolts | 0.010 max | 1.0 max | 0.08 max | 2.5 max | 0.03 max | Bal | 14.5 – 16.5 | 4 – 7 | 15 – 17 | 3 – 4.5 | 0.35 max | 0.04 max |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Hastelloy C276 Bolts | 8.89 g/cm3 | 1370 °C (2500 °F) | Psi – 1,15,000 , MPa – 790 | Psi – 52,000 , MPa – 355 | 40 % |
Hastelloy C276 bolts are a highly preferred material in the following types of industries: chemical processing plants that deal with very aggressive acids, chlorides and oxidisers; petrochemical and oil/gas refineries, pipelines, reactors and offshore drilling rigs where wheather conditions can be harsh; power generation from coal, oil or gas-burning; pollution control equipment; desalination plants; and any application where there is a combination of hot, wet, and corrosive conditions. Due to their excellent resistance to pitting, long service life, and thermal stability, Hastelloy C276 bolts provide users with maximum safety and durability when fastening together components in high-pressure/temperatures and extremely corrosive conditions.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
