Majid Fasteners is a leading manufacturer and supplier of high-quality Hastelloy C276 stud bolts in Dubai, UAE, serving diverse industries with reliable and corrosion-resistant fastening solutions. Known for precision engineering and strict quality standards, Majid Fasteners delivers products that perform exceptionally in harsh environments, including chemical processing, marine, and oil & gas sectors. With a strong focus on durability, performance, and customer satisfaction, the company offers a comprehensive range of Hastelloy C276 stud bolts tailored to meet demanding project requirements. Majid Fasteners continues to be a trusted partner for clients seeking premium fastening solutions across the UAE and beyond.
Hastelloy C276 stud bolts use a nickel-molybdenum-chromium alloy with added tungsten and very low carbon, giving exceptional corrosion resistance. Typical composition includes high nickel (~57%), molybdenum (~16%), chromium (~15%), plus small amounts of iron, cobalt, manganese, and silicon. Mechanical properties include tensile strength around 690 MPa, yield strength near 283 MPa, and excellent ductility with roughly 40% elongation. These studs remain stable at elevated temperatures, resist pitting and stress-corrosion cracking, and ensure reliable performance in aggressive chemical, petrochemical, and marine environments.
| Specifications | ASTM B574 / ASME SB574 |
|---|---|
| Fasteners size | Bolt / Screw Size : M3 – M56 | 3/6″ to 2″ | Custom Sizes Nuts Size : M3 – M56 | 3/6″ to 2″ | Custom Sizes Washers Size : M3 – M56 | 3/6″ to 2″ | Custom Sizes Machine Screws Size : M1.6 – M12 Self Tapping Screw Size : No.2 – No. 14 |
| Fasteners Length | 3 mm to 200 mm |
| Fastener Threads | UNF, BSW, BSF, METRIC, UNC or as required |
| Standard of High Nickel Alloy Fasteners | DIN : DIN 934, DIN 931, DIN 970, DIN 933 UTS : UNEF, NPT, UNC, UNS, UNF, NPTF ISO : JIS standards, ISO 4033, ISO 4032, ANSI – American National Standards Institute ASME B18.5 ANSI B 28.2.4 1M as per defined in ASME B16.5 standard Stud Bolt length ANSI B 18.2.4 2M as per defined in ASME B18.2.2 Hex nuts |
| Dimensions | DIN 931, 933, 934, 7991, 976, 125, ASME B18.2.1, B18.3 |
| Surface Coating | Ptfe Coated High Nickel Alloy Fasteners Phosphate Coating Teflon Coating Zinc Coating Hot Dipped Galvanizing Coating Cadmium Coating Xylon Coating |
| Fasteners Finishing | High Nickel Alloy : Self-Colour, Passivated, Bright Zinc Plated (BZP), Hot Dip Galvanised (HDG), High Nickel Alloy, Sherardized, some special one like DACROMET Geometry and Mechanically Applied coating ,Dacroment, nickel plated, anodizing, plated zinc-nickel Zinc (blue, black, yellow, white), black oxide. |
| Grade | C | Mn | Si | Co | S | Ni | Cr | Fe | Mo | W | V | P |
| Hastelloy C276 Stud Bolts | 0.010 max | 1.0 max | 0.08 max | 2.5 max | 0.03 max | Bal | 14.5 – 16.5 | 4 – 7 | 15 – 17 | 3 – 4.5 | 0.35 max |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Hastelloy C276 Stud Bolts | 8.89 g/cm3 | 1370 °C (2500 °F) | Psi – 1,15,000 , MPa – 790 | Psi – 52,000 , MPa – 355 | 40 % |
Hastelloy C276 stud bolts are widely used in demanding environments where exceptional corrosion resistance and mechanical reliability are essential. They are commonly applied in chemical processing equipment, including reactors, heat exchangers, and pressure vessels handling acidic or chloride-rich media. In petrochemical plants, they secure piping and flanges exposed to sour gas and high-temperature operations. Power generation units use them in scrubbers and pollution-control systems due to their resistance to pitting and crevice corrosion. Additionally, marine and offshore industries rely on these studs for saltwater-exposed structures, pumps, and valves, ensuring long-term performance in highly corrosive environments.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
