Majid Fasteners stands out as a top manufacturer and supplier of Stainless Steel 304H Nuts in Dubai, UAE. They specialize in providing industrial-grade fastening solutions that are built to last, ensuring superior durability and performance. Thanks to their state-of-the-art manufacturing facilities and rigorous quality control processes, the company guarantees products that not only meet international standards but also deliver exceptional strength and corrosion resistance.
The composition of Stainless Steel 304H Nuts includes 18–20% Chromium, 8–10.5% Nickel, up to 2% Manganese, 0.75% Silicon, and 0.04–0.10% Carbon, along with trace amounts of Phosphorus and Sulfur. The higher carbon content boosts their strength at elevated temperatures and enhances mechanical stability. These nuts boast a minimum tensile strength of around 515 MPa and a yield strength close to 205 MPa, all while maintaining excellent ductility and toughness. They can withstand high temperatures of up to approximately 870°C and show remarkable resistance to oxidation and corrosion, making them perfect for critical engineering applications.
| Specifications | DIN, ISO ,JIS ,GB, IS, BS, ASTM |
| Standard | ASTM A193 / A194, ASME SA193 / SA194 |
| Size | M2 – M100 |
| Length | 3 mm to 200 mm | Custom Sizes |
| Dimensions Standard | DIN: DIN931, 933, 934, 7991, 976, 125 ISO: ISO 4033, 4032 ASME B18.5, B18.3 |
| Form | Hex, Threading, Square, Round as per Gauge Etc. |
| Threads | Unless otherwise specified, the threads shall be rolled or cut and tapped horizontally or vertically |
| Threads available | UNF, BSW, BSF, METRIC, UNC, or as required |
| Threads Configuration | ASME B1.1 2A/3A – 2B/3B Inch Unified Threads and B1.13M 6h-6G Metric Coarse Threads |
| Certification | Dual Certified As per ASTM & ASME Codes |
| Test Certificate | As per EN 10204 / 3.1 Manufacturer Test Certificate, PED 97/23/EC Certified, Merkblatt AD 2000 W2 Certified |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | |
|---|---|---|---|---|---|---|---|---|---|---|
| 304H | min. | 0.04 | – | – | – | – | 18.0 | – | 8.0 | – |
| max. | 0.10 | 2.0 | 0.75 | 0.045 | 0.030 | 20.0 | – | 10.5 | – | |
| Grade | Tensile Strength (MPa) min | Yield Strength 0.2% Proof (MPa) min | Elongation (% in 50mm) min | Hardness | |
|---|---|---|---|---|---|
| Rockwell B (HR B) max | Brinell (HB) max | ||||
| 304H | 515 | 205 | 40 | 92 | 201 |
Stainless Steel 304H Nuts are commonly found in industries where high heat and corrosive environments are prevalent. They are frequently used in power plants, heat exchangers, boilers, and pressure vessels due to their ability to retain strength and resist scaling. Additionally, they are extensively utilized in petrochemical plants, refineries, marine equipment, thermal processing systems, and high-temperature piping assemblies. Their hygienic properties also make them a great fit for food processing and pharmaceutical machinery. Overall, these nuts are an outstanding choice for heavy-duty structural fastening, offering long-lasting durability, reliability, and top-notch performance in demanding conditions.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
