Situated in the heart of Addis Ababa, Tariku Metals has established itself as a trusted local source for high-performance materials, directly supplying industry with essential components. We specialize in providing robust Hastelloy B2 forgings, a niche yet critical product for demanding industrial environments. Our focus is on delivering not just a product, but a reliable solution that supports the growth and integrity of local engineering projects, ensuring our clients have access to world-class materials backed by our dedicated service and deep understanding of the regional market’s unique needs.
These bolts are primarily made up of chromium (24–26%) and nickel (19–22%), with a touch of carbon that boosts their strength when the heat is cranked up. They boast impressive tensile strength ranging from 515 to 690 MPa and a yield strength of about 205 MPa, along with excellent creep resistance and thermal stability. Their mechanical properties hold strong even in extreme heat, and their unique composition helps them resist oxidation, scaling, and thermal fatigue. This makes SS 314 Bolts a solid choice for long-term use in high-temperature settings.
| Standard | ASTM B564, ASME SB564 |
| Specification | DIN, ASTM, BS and all International Standards |
| Flat bar blocks | up to 27″ width and 15,000 lbs. |
| Cylinders and sleeves | up to 50″ maximum O.D. and 65″ maximum length |
| Discs and hubs | up to 50″ diameter and 20,000 lbs. |
| Rolled, hand forged or mandrel forged rings | up to 84″ maximum O.D. and 40″ maximum length |
| Rounds, shafts and step shafts | up to 144″ maximum length and 20,000 lbs. |
| Forging Types | Impression Die Forging, Open Die Forging, Seamless Rolled Forging, Hot Forging, Cold Forging, Open die hammer forging, Impression die drop forging, Closed Die Forging, Press Forging, Upset Forging, Compression Forging, Swaging, Rotary Forging, Roll forging. |
| Element | Content (%) |
|---|---|
| Iron, fe | Balance |
| Chromium, Cr | 23-26 |
| Nickel, Ni | 19-22 |
| Manganese, Mn | 2 |
| Silicon, Si | 1.5-3 |
| Carbon, C | 0.25 |
| Sulfur, S | 0.03 |
| Phosphorous, P | 0.045 |
| Properties | Metric | Imperial |
|---|---|---|
| Tensile strength | 689 MPa | 99900 psi |
| Yield strength | 345 MPa | 50000 psi |
| Modulus of elasticity | 200 GPa | 29000 ksi |
| Elongation at break (in 50 mm) | 40% | 40% |
| Hardness, Rockwell B | 85 | 85 |
You’ll find Stainless Steel 314 Bolts in action across industrial furnaces, heat exchangers, boiler assemblies, and thermal processing units. They’re also commonly used in power plants, chemical processing equipment, and petrochemical facilities, where components face high temperatures and corrosive conditions. Their ability to maintain strength, resist scaling, and keep their structural integrity under thermal stress makes them an ideal pick for securing equipment and structural assemblies in demanding high-temperature applications.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
