Majid Fasteners has earned a solid reputation as a reliable manufacturer and supplier of Stainless Steel 317/317L Stud Bolts right here in Dubai, UAE. They specialize in providing top-notch fastening solutions that are built to withstand the toughest industrial conditions. These stud bolts are particularly known for their outstanding corrosion resistance, crafted with precision to meet international standards and ensure they last. Majid Fasteners employs cutting-edge production methods along with rigorous quality control to create products that are perfect for chemical, marine, petrochemical, and high-temperature applications. With a strong focus on durability, reliability, and keeping customers happy, the company delivers Stainless Steel 317/317L Stud Bolts that perform exceptionally well in harsh environments, supporting critical infrastructure across a variety of industries.
Stainless Steel 317/317L Stud Bolts are high-molybdenum austenitic fasteners designed to provide superior resistance to corrosion and pitting compared to standard 300-series grades. They include chromium, nickel, molybdenum, and a lower carbon content in the 317L variant, which enhances weldability and reduces carbide precipitation. On the mechanical side, these fasteners boast excellent tensile strength, good elongation, and stability even at elevated temperatures. Their austenitic structure contributes to their toughness and durability, ensuring they perform reliably in aggressive chemical settings, acidic environments, and chloride-rich conditions.
Material | Specification | Standards | Size | Length |
Stainless Steel 317 / 317L Stud bolt | IS BS ASTM | ASTM / ASME – A/ SA 193 | 3 mm to 200 mm | M02 to M33 |
| Grade | C | Mn | Si | P | S | Cr | Ni | Mo | N |
| SS 317 | 0.08 max. | 2.00 max. | 1.00 max. | 0.045 max. | 0.03 max. | 18.0 – 20.0 | 11.0 – 14.0 | 3.0 – 4.0 | – |
| SS 317L | 0.03 max. | 2.00 max. | 0.75 max. | 0.045 max. | 0.03 max. | 18.0 – 20.0 | 11.0 – 15.0 | 3.0 – 4.0 | 0.1 |
| Grade | Tensile Strength (MPa) min | Yield Strength 0.2% Proof (MPa) min | Elongation (% in 50mm) min | Hardness | |
| Rockwell B (HR B) max | Brinell (HB) max | ||||
| 317 | 620 MPa | 275 MPa | 45% | 85 | 193 |
| 317L | 595 MPa | 260 MPa | 55% | 85 | 200 |
| STANDARD | WERKSTOFF NR. | UNS |
| Hastelloy B2 | 2.4617 | N10665 |
These Stainless Steel 317/317L Stud Bolts find their place in industries that demand exceptional resistance to chemical attacks, high temperatures, and corrosive substances. You’ll commonly see them in chemical processing plants, petrochemical facilities, refineries, pulp and paper mills, food processing equipment, desalination units, and marine settings. Thanks to their enhanced molybdenum content, they are ideal for fastening components that are exposed to chlorides, acidic solutions, and high humidity. These stud bolts are frequently used in heat exchangers, pressure vessels, reactors, boilers, pipelines, and pollution control equipment. The low-carbon 317L grade is particularly noteworthy for its performance in these challenging environments.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
